BK-TC Features
* Higher precision of temperature control
* Faster heating and cooling speed
* Better block temperature uniformity
* Smaller instrument dimension
* More silent operation environment
* Advanced thermoelectric cooling technology and creative TAS technology
Models:
|
Model |
BK-EO |
BK-TC |
|
Sample Capacity |
96-PCR plate(full-skirted) 96*0.2ml tubes 12*8-strip |
|
|
Cooling Technology |
Peltier-based |
|
|
Display |
LCD display and touch creen(5.7 inch) |
6.5 inch, 262 144 color LCD display and touch screen |
|
Temp. Range |
4.0~99.9℃ |
|
|
Heating Speed Of Ramping |
Up to 4℃/sec |
|
|
Cooling Speed Of Ramping |
Up to 4℃/sec |
|
|
Temp. Uniformity |
≤±0.3℃ |
≤±0.2℃ |
|
Temp. Accuracy |
≤±0.1℃(50℃), ≤±0.2℃ (≥90℃) |
|
|
Temp. Control Modes |
BLOCK or TUBE |
|
|
Ramping Range Adjustable |
0.1℃~4℃ |
|
|
Memory |
≥250 typical programs onboard, unlimited with USB flash drive expansion |
|
|
Max. No. Of Cycle |
99. Suitable for nested PCR |
|
|
Time Up/Down |
0~9 min59s, suitable for long PCR |
|
|
Temp. up/down |
0~9.9℃,suitable for touchdown PCR |
|
|
Auto Pause/Power Protection |
yes |
|
|
Soak Function |
Yes |
|
|
Gradient Range Of Temp. Difference |
1~30℃ |
|
|
Gradient Range |
30~99.9℃ |
|
|
Hot-lid Temp. Range |
Room temperature +5℃~110℃(default 105℃) |
|
|
Height Of Hot-lid |
Automatic Adjusted |
|
|
Auto Shut-off Function Of Hot Lid |
While block temperature is lower than set temperature or program ends, the hot-lid will be automatically closed |
|
|
Communication Interface |
USB |
LAN |
|
Power Supply |
100~240V, 50/60Hz, 600W |
|
|
Dimension |
335*260*270mm |
345*260*270mm |
|
Packing Size(L*W*H) |
495*410*395mm |
|
|
Gross Weight |
10.5kg |
12.5kg |
|
Certificates |
Ferrotec Peltier/CE/RoHS2.0 |
|
