Application:
It is suitable for the detection of prothrombin time (PT), activated partial thromboplastin time (APTT), thrombin time (TT) and fibrinogen (FIB) in plasma. .
Widely used in blood laboratory, biochemical laboratory, hospital blood laboratory and so on.
Features
●Dual-channel independent detection, can analyze different items at the same time
●5-inch high-definition touch screen, easy to operate
●Open system, good compatibility, Supports reagents of various specifications
●20,000 results storage
●Equipped with multiple pre-temperature positions to improve detection efficiency
●Built-in thermal printer
●The pipette automatically triggers the measurement, and the measurement time can be accurate to tenths of a second
●Less reagent consumption
Technical Parameter:
|
Model |
BK-CA02 |
BK-CA04 |
|
Test Principle |
Optical Colorimetry |
|
|
Test Items |
PT, APTT, TT, FIB |
|
|
Test Channel |
2 (can test different projects at the same time) |
4 (can test different projects at the same time) |
|
Wavelength |
470nm |
|
|
Detection Time |
Normal sample detection time is 20 to 40 seconds, and can be set arbitrarily from 20 to 99 seconds |
|
|
Sample Incubation Position |
12 |
24 |
|
Reagent Incubation Position |
5 |
6 |
|
Detection Position Temperature |
37.0±1.0°C |
|
|
Incubation Position Temperature |
37.0±1.0°C |
|
|
Incubation Time |
1-999s |
|
|
Reaction Time |
1-99s |
|
|
Reagent Dosage |
Minimum dosage 20μl |
|
|
20μl~40μl |
||
|
Display |
5-inch high-definition color touch screen |
|
|
Storage |
20,000 results storage, automatically save measurement data when power off |
|
|
Communication Interface |
RS232 serial interface, support LIS system |
|
|
Printer |
Built-in thermal printer |
|
|
Power Supply |
AC100~240V, 50/60Hz |
|
|
Consumption |
70VA |
|
|
Ambient Temperature |
10℃～30℃ |
|
|
Relative Humidity |
≤80% |
|
|
Atmospheric Pressure |
86kPa~106kPa |
|
|
External Size (W* D*H) |
360*210*120mm |
390*250*135mm |
|
Net Weight |
3.5kg |
4.96kg |
|
Package Size (W* D*H) |
376*246*316mm |
445*305*265mm |
|
Gross Weight |
5Kg |
7kg |
