Technical Parameters:
Model |
BCM-12A |
BCM-12B |
Measuring Range |
0-1200ml |
|
Measuring Accuracy |
2% |
|
Display Accuracy |
1ml |
|
Liquid Proportion |
1.05g/ml |
|
Collection Speed |
0.5~3ml/s |
|
Swing Frequency |
30-32 r/min |
|
Swing Angle |
13±2° |
|
Alarm |
Audio and visual alarm |
Audio and visual alarm with interrupter |
Interrupter Thrust |
/ |
<14N |
Consumption |
12W |
40W |
Power Supply |
AC110/220V±10%» 50/60HZ |
|
External Size(W*D*H) |
218*172*160mm |
275*230*210mm |
Packing Size(W*D*H) |
310*260*210mm |
330*280*260mm |
Net/Gross Weight |
2.8kg/3.5kg |
4.2kg/5.5kg |
