Technical Parameters:
|
Working Principle |
High-frequency inductive combustion and infrared absorption system |
|
Sample Weight (Solid steel) |
Standard 0.5g |
|
Accuracy |
C/S: 0.1 ppm |
|
Analysis Time |
25-60s adjustable (normally: 35s) |
|
Working Cycle |
24 hours |
The difference between BK-CSA5 and BK-CSA6:
|
Model |
BK-CSA5 |
BK-CSA6 |
|
Appearance |
Desktop detector, with desktop high-frequency furnace, save space |
Separate work station, with vertical high-frequency furnace |
|
Analysis Range |
C: 0.0005%-6.0000% (can be extended to 99.999%) S: 0.0005%-0.5000% (can be extended to 99.999%) |
C: 0.0001 %-10.0000% (can be extended to 99.999%) S: 0.0001 %-3.50000% (can be extended to 99.999%) |
|
Analysis Pool |
2 pools |
2 pools (optional 4 pools) |
|
Consumption |
2.2KW |
2.5KW |
|
Power Supply |
AC220V±10%, 50/60HZ |
|
|
Package Size(W*D*H) |
1380*760*980mm |
1670*750*960mm, 750*580*1430mm |
|
Gross Weight |
193kg |
150kg, 180kg |
|
Standard Accessories |
Main unit, high frequency automatic inductive combustion furnace, electric balance |
|
|
1000 times effective analysis of spare parts |
||
