A thin film of pure carbon deposited on one side of the grid. The thickness range is as follows:
Standard: Approx. 5-6nm
Ultra-Thin (UL): 3-4nm
Thick (TH): 10nm
Extra Thick (ET): 20-30nm
NOTE: All of our film is laid on the shiny side of the grid.
| Thomas No | Mfr No | Description |
|---|---|---|
| 1172Z96 | CF100H-Cu-UL | Carbon Support Film, Hexagonal Grid, 100 mesh, 3-4nm, Copper |
| 1172Z97 | CF100H-Cu-TH | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Copper |
| 1172Z98 | CF100H-Cu-ET | Carbon Support Film, Hexagonal Grid, 100 mesh, 20-30nm, Copper |
| 1172Z99 | CF100H-Ni-UL | Carbon Support Film, Hexagonal Grid, 100 mesh, 3-4nm, Nickel |
| 1171A00 | CF100H-Ni-TH | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Nickel |
| 1171A01 | CF100H-Ni-ET | Carbon Support Film, Hexagonal Grid, 100 mesh, 20-30nm, Nickel |
| 1171A02 | CF100H-Au-UL | Carbon Support Film, Hexagonal Grid, 100 mesh, 3-4nm, Gold |
| 1171A03 | CF100H-Au-TH | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Gold |
| 1171A04 | CF100H-Au-ET | Carbon Support Film, Hexagonal Grid, 100 mesh, 20-30nm, Gold |
| 1171A05 | CF200H-Cu-UL | Carbon Support Film, Hexagonal Grid, 200 mesh, 3-4nm, Copper |
| 1171A06 | CF200H-Cu-TH | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Copper |
| 1171A07 | CF200H-Cu-ET | Carbon Support Film, Hexagonal Grid, 200 mesh, 20-30nm, Copper |
| 1171A08 | CF200H-Ni-UL | Carbon Support Film, Hexagonal Grid, 200 mesh, 3-4nm, Nickel |
| 1171A09 | CF200H-Ni-TH | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Nickel |
| 1171A10 | CF200H-Ni-ET | Carbon Support Film, Hexagonal Grid, 200 mesh, 20-30nm, Nickel |
| 1171A11 | CF200H-Au-UL | Carbon Support Film, Hexagonal Grid, 200 mesh, 3-4nm, Gold |
| 1171A12 | CF200H-Au-TH | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Gold |
| 1171A13 | CF200H-Au-ET | Carbon Support Film, Hexagonal Grid, 200 mesh, 20-30nm, Gold |
| 1171A14 | CF300H-Cu-UL | Carbon Support Film, Hexagonal Grid, 300 mesh, 3-4nm, Copper |
| 1171A15 | CF300H-Cu-TH | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Copper |
| 1171A16 | CF300H-Cu-ET | Carbon Support Film, Hexagonal Grid, 300 mesh, 20-30nm, Copper |
| 1171A17 | CF300H-Ni-UL | Carbon Support Film, Hexagonal Grid, 300 mesh, 3-4nm, Nickel |
| 1171A18 | CF300H-Ni-TH | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Nickel |
| 1171A19 | CF300H-Ni-ET | Carbon Support Film, Hexagonal Grid, 300 mesh, 20-30nm, Nickel |
| 1171A20 | CF300H-Au-UL | Carbon Support Film, Hexagonal Grid, 300 mesh, 3-4nm, Gold |
| 1171A21 | CF300H-Au-TH | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Gold |
| 1171A22 | CF300H-Au-ET | Carbon Support Film, Hexagonal Grid, 300 mesh, 20-30nm, Gold |
| 1171A23 | CF400H-Cu-UL | Carbon Support Film, Hexagonal Grid, 400 mesh, 3-4nm, Copper |
| 1171A24 | CF400H-Cu-TH | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Copper |
| 1171A25 | CF400H-Cu-ET | Carbon Support Film, Hexagonal Grid, 400 mesh, 20-30nm, Copper |
| 1171A26 | CF400H-Ni-UL | Carbon Support Film, Hexagonal Grid, 400 mesh, 3-4nm, Nickel |
| 1171A27 | CF400H-Ni-TH | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Nickel |
| 1171A28 | CF400H-Ni-ET | Carbon Support Film, Hexagonal Grid, 400 mesh, 20-30nm, Nickel |
| 1171A29 | CF400H-Au-UL | Carbon Support Film, Hexagonal Grid, 400 mesh, 3-4nm, Gold |
| 1171A30 | CF400H-Au-TH | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Gold |
| 1171A31 | CF400H-Au-ET | Carbon Support Film, Hexagonal Grid, 400 mesh, 20-30nm, Gold |
| 1171F38 | CF100H-Cu-25 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Copper |
| 1171F39 | CF100H-Cu-50 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Copper |
| 1171F40 | CF100H-Ni-25 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Nickel |
| 1171F41 | CF100H-Ni-50 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Nickel |
| 1171F42 | CF100H-Au-25 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Gold |
| 1171F43 | CF100H-Au-50 | Carbon Support Film, Hexagonal Grid, 100 mesh, 10nm, Gold |
| 1171F44 | CF200H-Cu-25 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Copper |
| 1171F45 | CF200H-Cu-50 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Copper |
| 1171F46 | CF200H-Ni-25 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Nickel |
| 1171F47 | CF200H-Ni-50 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Nickel |
| 1171F48 | CF200H-Au-25 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Gold |
| 1171F49 | CF200H-Au-50 | Carbon Support Film, Hexagonal Grid, 200 mesh, 10nm, Gold |
| 1171F50 | CF300H-Cu-25 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Copper |
| 1171F51 | CF300H-Cu-50 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Copper |
| 1171F52 | CF300H-Ni-25 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Nickel |
| 1171F53 | CF300H-Ni-50 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Nickel |
| 1171F54 | CF300H-Au-25 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Gold |
| 1171F55 | CF300H-Au-50 | Carbon Support Film, Hexagonal Grid, 300 mesh, 10nm, Gold |
| 1171F56 | CF400H-Cu-25 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Copper |
| 1171F57 | CF400H-Cu-50 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Copper |
| 1171F58 | CF400H-Ni-25 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Nickel |
| 1171F59 | CF400H-Ni-50 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Nickel |
| 1171F60 | CF400H-Au-25 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Gold |
| 1171F61 | CF400H-Au-50 | Carbon Support Film, Hexagonal Grid, 400 mesh, 10nm, Gold |
