Introduction:
The CO2 incubator is a device for in vitro culture of cells/tissues, which can simulate the growth environment of cells/tissues in the chamber, such as constant pH (pH: 7.2-7.4) and stable temperature. (37°C), high relative humidity (90%), stable CO2 level (5%).
Features:
* Air jacket: with 140/160 ℃ hot air sterilization function.
* Equipped with USB port and LCD touch screen, the incubator can save data in real time.
* High quality infrared CO2 sensor for accurate CO2 concentration.
* The working chamber adopts round angle structure, easy to clean.
* High quality HEPA filter ensures the inside gas quality.
* SMC brand gas circuit valves ensure more stable gas concentration and less consumption of gas.
* The internal components do not need to be disassembled during sterilization, which is convenient and simple to use.
Model:
|
Model |
BJPX-C160D |
|
Capacity |
160L |
|
Temp. Range |
RT+5~60 ℃ |
|
Control Type |
Microcomputer controller |
|
Temp. Fluctuation |
±0.2 ℃(at 37℃) |
|
Temp. Uniformity |
±0.3 ℃(at 37℃) |
|
Time Setting |
0-999h or continuous |
|
Alarm |
Audible and visual alarm; Over-temperature alarm; Gas Concentration alarm |
|
Shelves |
2 pcs/ adjustable |
|
Material |
External cold-rolled steel with painting; Internal stainless steel |
|
Door |
Single door with heating function |
|
CO2 Range |
Infrared sensor, range 0~20% |
|
CO2 Control Resolution |
0.1% |
|
Humidification Type |
Water tank for natural evaporation |
|
Sterilization Type |
With 140/160 ℃ hot air sterilization function |
|
Ambient Temp. & Humidity |
5~30℃, suggest 25±2℃; Relative humidity ≤80% |
|
Caster |
Foot master caster |
|
Consumption |
700W/1550W (Hot air sterilization) |
|
Accessory |
Standard: 5.0 inch touch screen, CO2 two-stage pressure reducing valve, USB port, HEPA filter, Water tank |
|
Power Supply |
AC220V±10%, 50/60Hz(Standard) AC110V±10%, 60Hz(Optional) |
|
Internal Size(W*D*H)mm |
460*551*646 |
|
External Size(W*D*H)mm |
710*756*1107 |
|
Packing Size(W*D*H)mm |
780*836*1137 |
|
Gross Weight(kg) |
110 |
