Technical Parameters:
Series | BDV-1 | BDV-2 | ||||
Model | BDV-1 A | BDV-1 B | BDV-1 C | BDV-2A | BDV-2B | BDV-2C |
Measured Range (mPas) | 12〜6M | 80 〜40M | 640-320M | 6〜6M | 40-40M | 320-320M |
Rotation Speed(rpm) | 0.1*99.9 non-polar shift | 0.1-200 non-polar shift | ||||
Number of Spindle | 4 (L1〜L4) | 6 (R2-R7) | 6 (R2-R7) | 4 (L1~L4) | 6 (R2-R7) | 6 (R2-R7) |
Measurement Accuracy | ±1%(FS) (Newtonian Fluid) | |||||
Repeatability | ±0.5%(FS) (Newtonian Fluid) | |||||
Power Supply | AC 100-240V, 50/60HZ | |||||
Standard accessory | RS232 standard output interface,RTD temperature probe | |||||
Optional accessory | Specially used printer | |||||
L0 Spindle is for Option Measured Range (mPas) | 0.6〜6000 | 6-60000 | 50-500000 | 0.3-6000 | 3-60000 | 25-500000 |
R1 Spindle is for Option Measured Range (mPas) | / | 20〜100000 | 160〜800000 | / | 10-100000 | 80〜800000 |
Package Size(mm) | 400*350*360 | 400*350*550 | 400*350*550 | 400*350*360 | 400*350*550 | 400*350*550 |
Gross Weight(kg) | 9 | 10.5 | 10.5 | 9 | 10.5 | 10.5 |
