Features
1.Safe and reliable
2.High thermal efficiency
3.Fast steam production
4.Steam is cleaner
5.Fully automatic control
6.Multiple alarm protection
Technical Parameters
|
Model |
BK-ZFQ-96 |
BK-ZFQ-120 |
|
Rated Steam Capacity |
120kg/h |
150kg/h |
|
Rated Working Pressure |
0.65MPa |
0.65MPa |
|
Rated Steam Temp. |
168℃ |
168℃ |
|
Water Volume |
23L |
23L |
|
Electric Heating Power |
96KW |
120KW |
|
Power Supply |
380v50Hz |
|
|
External Size |
1315*880*1790mm |
1315*880*1790mm |
|
Packing Size |
1480*1030*2110 |
1480*1030*2110 |
|
Gross Weight |
500kg |
500kg |
