Features:
●The software supports automatic potential tracking correction to ensure stable performance
●Automatic monitoring and filtering of tiny air bubbles to ensure measurement accuracy
●Wave flushing and pipeline flushing can avoid blockage and cross-contamination
●Power-off protection, can protect data storage, the result can be stored up to 50,000
●Low consumption, effectively reducing the cost of consumables
●7-inch high-definition touch screen, comprehensive content display
●With the function of automatic fault alarm and elimination, improve work efficiency
Parameters:
|
Model |
BKE Series |
|
Sample |
Serum, plasma, whole blood, cerebrospinal fluid and dilute urine |
|
Measuring Speed |
≤25s |
|
Analysis Method |
Ion selective electrode (ISE) |
|
Sample Volume |
60~150μl |
|
Sample Position |
30 sample positions, 5 emergency positions, 2 QC positions |
|
Injection mode |
Manual or automatic injection can be selected |
|
Storage |
Up to 50,000 test results |
|
Printer |
Build-in thermal printer |
|
Interface |
RS232 port for LIS |
|
Display |
7-inch high-definition touch screen |
|
Language |
Chinese and English, other languages can be customized |
|
Calibration |
Automatic and Manual calibration |
|
Other Function |
Sample volume detection |
|
Temperature |
10~30℃ |
|
Relative Humidity |
≤ 80 % |
|
Atmospheric Pressure |
86~106 kPa |
|
Model |
BKE-A |
BKE-B |
BKE-C |
BKE-D |
|
Test Items |
K+, Na+, Cl– |
K+, Na+, Cl– |
K+, Na+, Cl–, iCa2+, nCa2+, TCa2+, pH |
K+, Na+, Cl–, iCa2+, nCa2+, TCa2+, pH |
|
Sample Tray |
No |
Yes |
No |
Yes |
|
External Size(W*D*H) |
390*200*434mm |
660*276*434mm |
390*200*434mm |
660*276*434mm |
|
Net Weight |
6.85kg |
10.3kg |
6.85kg |
10.3kg |
|
Package Size(W*D*H) |
540*420*520 mm |
540*420*705 mm |
540*420*520 mm |
540*420*705 mm |
|
Gross Weight |
7.5kg |
10.95kg |
7.5kg |
10.95kg |
|
Items |
Measuring Range |
Resolution |
|
K+ |
0.5-20.0mmol/L |
0.01 mmol/L |
|
Na+ |
15-200mmol/L |
0.1 mmol/L |
|
Cl– |
15-200mmol/L |
0.1 mmol/L |
|
Ca2+ |
0.1-6.0mmol/L |
0.01 mmol/L |
|
pH |
4-9pH |
0.01 pH |
