Technical Parameters:
|
Model |
ZPSXF-I |
|
Top Frame |
Top side beam 2.0mm thick |
|
Top beam C100*40mm*1.2mm, 9 PCS |
|
|
Ridge square tube 30*30mm*1.0mm |
|
|
Top rock wool 80mm thick |
|
|
PE protective film |
|
|
Top color steel tile 0.35mm thick |
|
|
Roof Structural Adhesive |
|
|
Butyl waterproof tape, 2mm thick |
|
|
Bottom Frame |
Underframe side beam 2mm thick |
|
Underframe beam 100*50*1.2mm, 9pcs |
|
|
Bottom frame longitudinal reinforcement beam |
|
|
Prism |
210*150*2.0mm column, height 2550mm |
|
Stud Bolt M10*25 |
|
|
Column connector |
|
|
Corner Piece |
210*160 corner piece, 8pcs |
|
top triangle support |
|
|
Color |
RAL9010 |
|
Panel |
Double-sided rock wool sandwich panel, 50mm thick |
|
Floor |
Cement fiber board 18mm thick |
|
Floor Decoration |
PVC floor 1.6mm thick |
|
Door |
970*1970mm, Common fire lock, white steel window |
|
Window |
PVC window |
|
Others |
Floor groove, galvanized iron sheet |
|
PVC drain pipe, φ50mm |
|
|
Ceiling trim |
|
|
Column inner corner |
