Application:
It is suitable for in vitro diagnostic tests in central laboratories, outpatient/emergency laboratories, clinical departments, physical examination centers and scientific research laboratories of medical institutions.
Features:
-
12 independent constant temperature incubation channels, which can detect 12 different items at the same time
-
Automatic induction of reagent card insertion, automatic printing of test results, and automatic card loss.
-
Built-in thermal printer, can also be connected to an external printer.
-
10.1-inch large LCD screen with a resolution of 800*480 or more, the visual experience is better.
-
The temperature range can be manually set to quickly achieve the predetermined temperature effect and improve the reaction rate.
-
The operation is convenient, the data is automatically read, and the single detection time is less than 10s.
Technical Parameters:
|
Model |
BKP2000 |
|
Excitation light source |
LED |
|
Wavelength |
Excitation wavelength λ0=365nm Detection wavelength λ1=615nm |
|
Detection Channel |
1 |
|
Incubation Position |
12 |
|
Sample Type |
Serum, plasma, whole blood and urine, etc. |
|
Detection Mode |
Supports multiple items in one card |
|
Testing Speed |
＜10s/test |
|
Repeatability |
CV≤5% |
|
Stability |
σ≤±8% |
|
Linear Correlation |
(r)≥0.98 |
|
Accuracy |
Δn≤±8% |
|
Display |
10.1-inch color touch screen |
|
Language |
Chinese, English, Other languages can be customized |
|
Interface |
RS232, USB, Ethernet port |
|
Printer |
Built-in thermal printer |
|
Power Supply |
100~240V 50/60Hz |
|
External Size(L*W*H) mm |
336*410*400 |
|
Net Weight (kg) |
17 |
|
Package Size(L*W*H) mm |
610*530*715 |
|
Gross Weight (kg) |
36.5 |
