Features：
LCD liquid crystal temperature display, with temperature deviation calibration function.
The unique air duct design ensures the uniformity and stability of the temperature in the working room.
Over temperature alarm and automatic fault detection alarm function.
Independent fan switch, decide whether to open convection according to heating needs.
SUS 304 high quality chamber.
Optional Foot Master casters are available for more convenient movement.
Technical Parameters：
|
Model |
BJPX-HGZ23 |
BJPX-HGZ45 |
BJPX-HGZ54 |
BJPX-HGZ75 |
BJPX-HGZ88 |
|
Capacity |
23L |
45L |
54L |
75L |
88L |
|
Temp. Range |
RT+10℃~300℃ |
||||
|
Temp. Precision |
0.1℃ |
||||
|
Temp. Uniformity |
≤Max Temp.±2.5％ |
||||
|
Circulation Mode |
Back heating, forced convection |
||||
|
Timing Range |
0~9999min/h |
||||
|
Shelves NO. (pc) |
2 |
2 |
2 |
2 |
3 |
|
Display |
LCD |
||||
|
Power Supply |
100-245V 50/60Hz |
||||
|
Internal Size(mm) |
300*275*290 |
370*340*358 |
370*340*439 |
463*463*352 |
500*490*361 |
|
External Size(mm) |
490*415*535 |
596*635*510 |
596*635*610 |
691*635*615 |
727*650*666 |
|
Packing Size(mm) |
675*522*641 |
690*700*660 |
690*700*760 |
785*700*765 |
820*720*810 |
|
Gross Weight(kg) |
50 |
40 |
43.5 |
47 |
50.5 |
|
Model |
BJPX-HGZ138 |
BJPX-HGZ160 |
BJPX-HGZ225 |
BJPX-HGZ270 |
|
Capacity |
138L |
160L |
225L |
270L |
|
Temp. Range |
RT+10℃~300℃ |
|||
|
Temp. Precision |
0.1℃ |
|||
|
Temp. Uniformity |
≤Max Temp.±2.5％ |
|||
|
Circulation Mode |
Back heating, forced convection |
|||
|
Timing Range |
0~9999min/h |
|||
|
Shelves NO. (pc) |
3 |
3 |
3 |
3 |
|
Display |
LCD |
|||
|
Power Supply |
100-245V 50/60Hz
|
220V±10% 50/60Hz(Standard) ; 110V±10% 50/60Hz(Optional, |
||
|
Internal Size(mm) |
555*555*453 |
558*578*500 |
562*748*508 |
664*700*600 |
|
External Size(mm) |
781*725*705 |
785*793*764 |
826*780*900 |
891*891*876 |
|
Packing Size(mm) |
871*795*850 |
871*865*910 |
920*940*1050 |
990*960*1020 |
|
Gross Weight(kg) |
60 |
68.5 |
77 |
86.5 |
