Features:
* Overtemperature alarm, dew point overtemperature alarm, low water level alarm.
* Real-time curve, system temperature, humidity, dew point temperature can be viewed in the display screen.
* Temperature and humidity controller, touch screen and PLC control module, microcomputer automatic control.
* The box structure adopts jacket design.
* Power off protection function.
Technical Parameter:
Model | BJPX-FE801-3 |
Temp Range | 15~40℃ |
Temp Accuracy | ±0.5℃ |
Humidity Range | |
Humidity Accuracy | ±3%RH |
Air Exchange Rate Range | 0.2~2m3/h(Air change rate 0.2~2 times/h) |
Air Exchange Rate Accuracy | Ventilation rate±1% |
0.1~2m/s | |
Air Rate Accuracy | ≤0.05m/s |
Test Chamber Size | 1±0.02m3 |
Internal Size | 800*1000*1150mm |
Pressure | 10±5Pa |
Sealing | |
Constant Temperature Box | Polyurethane and insulation board Outer wall: steel plate, white spraying Inner wall: 304 stainless steel plate |
Background Concentrations | Formaldehyde＜0.006mg/m3 TVOC＜0.05mg/m3 Single VOC＜0.005mg/m3 |
Consumption | Starting power≤4kw Running power 2kw |
Power Supply | Standard: 220V 50/60Hz Optional: 110V 50/60Hz |
External Size | 1750*1150*1860mm |
Net Weight | 450kg |
