It is used to quantitatively analyze the clinical chemistry of human serum, plasma, urine, cerebrospinal fluid and other samples. Do not use for other purposes.
Models：
|
Model |
BK-400 |
|
|
Overall Performance |
Throughput |
400 Test/hour |
|
Analysis Method |
End-point, Fixed-time, Rate(Kinetic), Turbidimetry |
|
|
Certification |
CE, FDA, ISO9001, ISO14001, ISO13485 |
|
|
Sample & Reagent System |
Sample Positions |
60 or 90 sample positions, built-in barcode system available |
|
Reagent Positions |
90 refrigerated reagent positions |
|
|
Sample Volume |
1-70μL |
|
|
Reagent Volume |
10-350μL |
|
|
Probe |
Teflon coating, with anti-collision function,liquid level detection function |
|
|
Probe Washing |
Automatic washing interior and exterior |
|
|
Reagent Cooling |
2~8℃ |
|
|
Reaction System |
Temperature Control |
37±0.1℃, real-time monitoring |
|
Cuvettes |
120reusable cuvettes, optical length 6mm |
|
|
Mixer Probe |
Independent stirring |
|
|
Washing |
Automatic cuvettes washing |
|
|
STAT function |
YES |
|
|
Optical System |
Light Source |
12V/30W halogen-tungsten lamp |
|
Spectrophotometry |
Post-spectral spectrophotometry |
|
|
Wavelength |
340,405,450,480,505,546,570,600,630,700,750,800nm |
|
|
Absorbance |
0~3.5Abs |
|
|
Calibration & QC |
Calibration |
Linear:K factor, 1-point ,2-point and multipoint linear |
|
Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
||
|
Quality Control |
Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D) |
|
|
Data Management |
Software |
Windows 7/8/10 , 32or 64bit |
|
LIS System |
Bi-direction,support HL7 protocol |
|
|
Interface |
LAN port access |
|
|
Printer |
External,multiple reporting mode available |
|
|
Working Conditions |
Power Supply |
AC220V±10%,50/60Hz, 110V±10%,60Hz, 500W |
|
Temperature |
15～30℃ |
|
|
Water Consumption |
Deionized water:10L/H |
|
|
Humidity |
40-85% |
|
|
Size & Weight |
External Size (W*D*H) |
1170*775*1145mm |
|
Net Weight |
190kg |
|
|
Package Size (W*D*H) |
1348*928*1377mm |
|
|
Gross Weight |
257kg |
|
