Technical Parameters:
|
Model |
BK-GC112A | |
|
Oven |
Capacity |
22L |
|
Temp. Range |
RT+5°C~400°C |
|
|
Temp. Accuracy |
±0.1 °C |
|
|
Temp. Program |
9 step |
|
|
Program Total Time |
9999.9 min |
|
|
Max Temp. Heating Rate |
60°C/min |
|
|
Sample Injector |
Temp. Range |
RT+7°C~420°C |
|
Column or split injector can be installed |
||
|
Carrier gas flow control type: Constant pressure mode |
||
|
Max. Quantity |
3pcs |
|
|
Pre Column Pressure Range |
0-400kpa |
|
|
Pre Column Pressure Accuracy |
0.1 kpa |
|
|
Flow Setting Range |
H2: 0-200ml/min |
|
|
N2: 0-150ml/min |
||
|
Detector |
Temp. Range |
RT+7°C~420°C |
|
Hydrogen Flame Ionization Detector (FID) |
Logarithmic amplifier |
|
|
High voltage switch control |
||
|
Baseline signal display |
||
|
Detection limit: ^3*1012g/s (Sample: n-hexadecane) |
||
|
Baseline noise: <5*1014A |
||
|
Baseline draft:《6*1 O ^A |
||
|
Dynamic range: 107 |
||
|
RSD: £3% |
||
|
Thermal Conductivity Detector (TCD)(Optional) |
Sensitivity: 8000mv.ml/mg(Sample: n-hexadecane) |
|
|
Baseline noise: <0.05mV |
||
|
Baseline draft: <0.15mV/30min |
||
|
Dynamic range: 105 |
||
|
Power Supply |
AC220V±10%, 50Hz |
|
|
Standard Accessory |
FID detector, Capillary injection system, Chromatography workstation software,RS232 port, LAN port |
|
|
Optional Accessory |
TCD detector, Chromatographic column, Gas purifier |
|
|
Package Size(W*D*H) |
735*725*835mm |
|
|
Gross Weight |
80kg |
|
