Feature:
1. One-handed control, user-friendly operation, super power, better experimental effect;
2. Double insulation protection to ensure safety;
3. All parts of the working head contacting the material are made of high-quality stainless steel, with good corrosion resistance;
4. The working head is connected with the drive motor by a coupling, which is easy and flexible to disassemble;
5. Stepless speed controller, convenient speed regulation and stable operation.
Technical Parameter:
|
Model |
BK-H6B |
|
Speed Range |
1000-35000r/min |
|
Working Volume |
0.2-150ml (H2O) |
|
Standard Dispersing Shaft |
10G |
|
Max. Viscosity |
5000mpas |
|
Consumption |
120W |
|
Speed Control |
6 stage |
|
Speed Controller |
Stepless speed controller, |
|
Material Of Dispersing Shaft |
SS316L & PTFE |
|
Process Type |
Micro batch processing |
|
Power Supply |
220V 50/60HZ |
|
Relative Humidity |
80% |
|
Optional Stand |
Single column stand |
|
Net Weight |
0.6kg |
|
Package Size(W*D*H) |
470*335*200mm |
|
Gross Weight |
6kg |
Dispersing Shaft:
|
Dispersing Shaft |
Type |
Working Volume （ml） |
Viscosity （cp） |
Speed（m/s） |
Length (mm） |
Diameter(mm) |
||
|
|
6G |
0.2-50 |
100 |
5 |
125 |
6 |
||
|
|
8G |
10-60 |
500 |
8 |
150 |
8 |
||
|
|
10G |
30-150 |
2000 |
10 |
185 |
10 |
||
|
|
6G-ST |
0.2-50 |
100 |
5 |
125 |
6 |
||
|
|
8G-ST |
10-60 |
500 |
8 |
150 |
8 |
||
|
|
10G-ST |
30-150 |
2000 |
10 |
185 |
10 |
||
