Features:
1.LCD display, indicating setting parameters and actual parameters at the same time.
2.Brushless motor: Controlled by micro chip’s dsPIC30F series SCM and driven by FAIR CHILD’S FSBB30CH series driver module.
3.Safety: over-speed and over-temperature protection, imbalance detection shock absorber to keep motor running smoothly.
4.Mute mechatronics motor door lock.
5.10 levels speed-up and speed-down control.
6.Over 20 selectable procedures and freely self-defining modes.
Models:
Model | BKC-VH20RII |
Max. Capacity | 4*750ml |
Max. Speed | 20600rpm |
Max. RCF | 29400xg |
Standard Rotor | 12*1.5/2.0ml |
Speed Precision | ±50rpm |
Refrigeration System | CFC-free (R404a) |
Temp. Range | –20°C~40°C |
Temp. Precision | ±1°C |
Control and Driven System | Frequency motor, micro control, direct driver |
Timing Range | 0~99h59min |
Noise | ≤65dB |
Identify Rotor | Automatic |
Consumption | 2.0KW |
Power Supply | AC110/220V, 50/60HZ |
External Size(W*D*H) mm | 710*560*770mm |
Package Size(W*D*H) mm | 885*705*1195 |
Net/Gross Weight(kg) | 160/218 |
Rotor:
Rotor | Capacity | Speed(rpm) | RCF(xg) | Rotor | Capacity | Speed(rpm) | RCF(xg) | |
Angle Rotor | 12*1.5/2.0ml | 20600 | 29400 | Angle Rotor | 8*15ml | 12000 | 14800 | |
Swing Rotor | 4*750ml/4*500ml | 4000 | 3500 | 6*50ml | 12000 | 13800 | ||
Available adaptor: 4*250/300ml,4*8*15ml, 4*12*10ml,4*3*50ml, 4*19*5ml (vacuum tube) | 4000 | 3580 | 8*50ml | 10000 | 10500 | |||
4*100ml | 10000 | 10500 | ||||||
6*100ml | 11000 | 14520 | ||||||
Angle Rotor | 24*1.5/2.0ml | 14000 | 18180 | 6*250ml | 8000 | 9200 | ||
12*5/10ml | 14000 | 18800 | Microplate | 2*2*96 well | 4000 | 2360 | ||
4*2*96 well | 4000 | 2910 | ||||||
