Technical Parameters:
|
Model |
SCSJ-II-60L |
SCSJ-II-80L |
SCSJ-II-100L |
|
|
Water Output Type |
RO water outlet* 1 and DI water outlet*1 |
RO water outlet* 1 and DI water outlet*2 |
||
|
Water Output Speed |
60 L/H |
80 L/H |
100 L/H | |
|
Purifying Procedure |
PF+AC+RO+DI |
|||
|
Water Supply Requirement |
When working, the inlet water pressure is 0.1-0.3Mpa, and the water quality meets the requirements of GB5749,15 ~ 35°C |
|||
|
Environmental Requirements |
Temperature 15 ~ 35°C Relative Humidity≤80% |
|||
|
Purification System |
Precision filter* 1; Deionization purification column*1 300GPD RO membrane*2 (SCSJ-ll-60L,SCSJ-ll-80L) |
|||
|
DI Water Quality |
Resistivity |
10-18.25MΩ.cm |
||
|
Conductivity |
0.055-0.1μs/cm |
|||
|
Heavy metal |
<0.1 ppb |
|||
|
Particle |
<1/ml |
|||
|
Bacteria |
<0.1cfu/ml |
|||
|
RO Water Quality |
Ion rejection rate |
96%~99% |
||
|
Organic rejection rate |
>99% |
|||
|
Particles and bacteria rejection rate |
>99% |
|||
|
Flow Rate |
2500ml/min |
|||
|
Consumption |
230W |
|||
|
Power Supply |
AC220V±10%, 50Hz±5% (Standard); AC110V, 60Hz (Optional) |
|||
|
Standard Configuration |
Main body , 50Lwater tank, accessory pack |
Main body , 20Lwater tank (0.5 gallon pressure tank), accessory pack |
||
|
Instrument Size(W*D*H) |
390*400*1000mm |
|||
|
Package Size(W*D*H) |
Instrument |
490*480*1100mm |
950*490*1100mm |
|
|
Tank |
415*415*700mm |
|||
|
Accessory Box |
680*400*230mm |
675*395*230mm |
||
|
Gross Weight |
45kg |
70kg |
||
