Features:
1. Speed up to 1500Orpm (15100×g)
2. Brushless DC motor drive quickly to the target speed
3. Quiet working,Low noise ≤54dB
4. Cast iron chassis, low center of gravity, vacuum suction cup feet, double safety guarantee.
5. Wide voltage design, the speed is not affected by voltage fluctuations, and the speed accuracy is high.
Models：
|
Model |
D2012 plus |
|
Max.Speed |
15000rpm(500-15000rpm)increment:100rpm |
|
Max.RCF |
15100×g,increment:100×g |
|
Speed Accuracy |
±20rpm |
|
Rotor Capacity |
2mL*12 |
|
Run Time |
30sec-99min/Continuous |
|
Acceleration/Braking Time |
11s↑/9s↓ |
|
Driving Motor |
Brushless DC motor |
|
Safety Devices |
Door interlock; Over-speed detection; |
|
Power |
Single-phase,AC100V-240V;50Hz/6OHz,3A;100W |
|
Noise Level |
≤54dB |
|
Dimension(D*W*H) |
255*245*140mm |
|
Package Size(D*W*H) |
455″345*250mm |
|
Gross Weight |
6.54kg |
|
Other Functions |
Speed/RCF switch;Short-time run function; |
Standard Outfit:
Adapted Rotor
|
Model |
A12-2P(19400010) |
|
Max.Speed |
15000rpm |
|
Max.RCF |
15100xg |
|
Rotor Capacity |
2mL*12 |
|
Rotor Material |
High strength plastic |
|
Adapted Rotor Adapter |
A02P2,A05P2 |
Optional Accessories:
Adapted Adapter
|
Model |
A02P2(19500001) |
A05P2(19500002) |
|
Descriptions |
0.2ml rotor adapter for A12-2,A12-2P, |
0.5ml rotor adapter for A12-2,A12-2P， |
