Features:
1. Independent nebulization card positions to avoid crowding and cross-infection.
2. 10-inch video animation player, increases interest in treatment, guides children nebulization.
3. One-button start and convenient operation.
4. Built-in medical nebulizer for reliable use.
The cartoon layout attracts children and reduces children’s sense of rejection of the hospital.
Parameters:
|
Model |
BK-NT-II |
|
Sheet Material |
16mm particle plates |
|
Environmental Protection Level |
Class E1 |
|
Card Position |
Double card position |
|
Dispiay |
10-inch TFT HD color screen |
|
Data Storage |
U disk and TF card storage, standard with 8G large capacity U disk |
|
Play Function |
Support for full-format video playback |
|
Built-in Compression Nebulizer Model |
BK-AN-IA (With registration certificate) |
|
Gas Flow Rate |
Compressor pump free air flow ≥10L/min |
|
Nebulization Rate |
Maximum Nebulization Rate ≥0.2ml/min |
|
Median Diameter of Mist Particle |
2.7μm±25%, the diameter of Mist particles less than 5μm accounted for > 65% |
|
Noise |
≤60dB(A) |
|
Input Power |
400VA |
|
Power Supply |
AC220V, 50/60Hz (Optional: AC110V, 60Hz) |
|
External Size (W*D*H) |
1249mm*600mm*1025mm |
|
Package Size（W*D*H） |
1000mm*600mm*600mm |
|
Gross Weight |
60kg |
