NUCLEODUR® is a fully synthetical type B silica (silica of 3rd generation) offering highly advanced physical properties:
- Totally spherical particle shape
- Outstanding surface microstructure
- High pressure stability
- Low metal content
NUCLEODUR® as a state-of-the-art silica is the ideal base material for modern HPLC phases. It is the result of MACHEREY-NAGEL’s pioneering research in chromatography for almost 50 years.
NUCLEODUR® PFP
Pentafluorophenyl-propyl modification, multi-endcapped, USP L43
Key features:
- Hydrophobic phase with alternative selectivity in comparison to classical C18 modifications
- Separation mechanism based on 4 retention mechanisms (polar interactions (H bonds), dipole-dipole interactions, π-π interactions, hydrophobic interactions)
- Suitable for LC/MS due to low bleeding characteristics
Technical characteristics:
- Phase with pentafluorophenyl-propyl modification and multi-endcapping
- Pore size 110 Å
- Particle sizes 1.8 µm (UHPLC), 3 µm and 5 µm
- pH stability 1–9
- Carbon content 8 %
Recommended application: Aromatic and unsaturated compounds, phenols, halogenated compounds, isomers, polar compounds like pharmaceuticals, antibiotics; high retention of basic compounds
| Thomas No | Mfr No | Description |
|---|---|---|
| 1151W56 | 760431.20 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 30 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W57 | 760431.30 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 30 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W58 | 760431.40 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 30 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W59 | 760431.46 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 30 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W60 | 760433.20 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 50 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W61 | 760433.30 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 50 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W62 | 760433.40 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 50 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W63 | 760433.46 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 50 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W64 | 760435.20 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 75 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W65 | 760436.20 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 100 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W66 | 760436.30 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 100 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W67 | 760436.40 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 100 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W68 | 760436.46 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 100 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W69 | 760438.20 | HPLC column (analytical), NUCLEODUR PFP, 1.8 µm, length: 150 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W70 | 760443.20 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 50 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W71 | 760443.30 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 50 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W72 | 760443.40 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 50 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W73 | 760443.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 50 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W74 | 760445.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 75 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W75 | 760446.20 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 100 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W76 | 760446.30 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 100 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W77 | 760446.40 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 100 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W78 | 760446.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 100 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W79 | 760447.20 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 125 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W80 | 760447.30 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 125 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W81 | 760447.40 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 125 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W82 | 760447.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 125 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W83 | 760448.20 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 150 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W84 | 760448.30 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 150 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W85 | 760448.40 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 150 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W86 | 760448.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 150 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W87 | 760449.20 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 250 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W88 | 760449.30 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 250 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W89 | 760449.40 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 250 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W90 | 760449.46 | HPLC column (analytical), NUCLEODUR PFP, 3 µm, length: 250 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W91 | 760453.20 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 50 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W92 | 760453.30 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 50 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W93 | 760453.40 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 50 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W94 | 760453.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 50 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W95 | 760455.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 75 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151W96 | 760456.20 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 100 mm, ID: 2mm, USP: L43, 1 Column |
| 1151W97 | 760456.30 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 100 mm, ID: 3mm, USP: L43, 1 Column |
| 1151W98 | 760456.40 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 100 mm, ID: 4mm, USP: L43, 1 Column |
| 1151W99 | 760456.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 100 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151X00 | 760457.20 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 125 mm, ID: 2mm, USP: L43, 1 Column |
| 1151X01 | 760457.30 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 125 mm, ID: 3mm, USP: L43, 1 Column |
| 1151X02 | 760457.40 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 125 mm, ID: 4mm, USP: L43, 1 Column |
| 1151X03 | 760457.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 125 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151X04 | 760458.20 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 150 mm, ID: 2mm, USP: L43, 1 Column |
| 1151X05 | 760458.30 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 150 mm, ID: 3mm, USP: L43, 1 Column |
| 1151X06 | 760458.40 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 150 mm, ID: 4mm, USP: L43, 1 Column |
| 1151X07 | 760458.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 150 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1151X08 | 760459.20 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 250 mm, ID: 2mm, USP: L43, 1 Column |
| 1151X09 | 760459.30 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 250 mm, ID: 3mm, USP: L43, 1 Column |
| 1151X10 | 760459.40 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 250 mm, ID: 4mm, USP: L43, 1 Column |
| 1151X11 | 760459.46 | HPLC column (analytical), NUCLEODUR PFP, 5 µm, length: 250 mm, ID: 4.6mm, USP: L43, 1 Column |
| 1150C12 | 761975.20 | HPLC guard column (analytical), NUCLEODUR PFP, 1.8 µm, length: 4 mm, ID: 2mm, USP: L43, 3 guard column |
| 1150C13 | 761975.30 | HPLC guard column (analytical), NUCLEODUR PFP, 1.8 µm, length: 4 mm, ID: 3mm, USP: L43, 3 guard column |
| 1150C14 | 761976.20 | HPLC guard column (analytical), NUCLEODUR PFP, 3 µm, length: 4 mm, ID: 2mm, USP: L43, 3 guard column |
| 1150C15 | 761976.30 | HPLC guard column (analytical), NUCLEODUR PFP, 3 µm, length: 4 mm, ID: 3mm, USP: L43, 3 guard column |
| 1150C16 | 761977.20 | HPLC guard column (analytical), NUCLEODUR PFP, 5 µm, length: 4 mm, ID: 2mm, USP: L43, 3 guard column |
| 1150C17 | 761977.30 | HPLC guard column (analytical), NUCLEODUR PFP, 5 µm, length: 4 mm, ID: 3mm, USP: L43, 3 guard column Request penawaran harga & konsultasi produk? Silakan isi form ini dan kami akan segera membalas ke kontak Anda!
