Features:
BK-FP3536:
* It adopts special heating furnace to ensure the safety of test.
* The heating power is continuously adjustable. It can meet requirements
of test.
* The instrument is fully self-contained complete. The operator can do determination as long as connecting with coal gas or other civil gas.
* With fast cooling function, it can improve test efficiency.
BK-FP3536D:
* 8-inch IPS high-definition capacitive screen, the test data and parameters
are displayed by curve in real time
* Automatic measurement of atmospheric pressure, automatic correction
of flash point value.
* Equipped with Bluetooth interface. The user can query test data anytime.
* Electronic ignition, gas flame.
* Remote automatic upgrade to obtain the latest version, remote prediction,
abnormal early warning, comprehensive evaluation and maintenance
of instrument operation status.
Technical Parameters:
|
Model |
BK-FP3536 |
BK-FP3536D |
|
Thermometer |
-6°C~400°C. It is the same as thermometer ASTM 11C |
|
|
Ambient Temperature |
15°C-35°C |
|
|
Relative Humidity |
≤85% |
|
|
Consumption |
≤650W |
≤750W |
|
Test Flame Applicator |
It applies the test flash automatically. |
|
|
Heating Device |
Furnace heating, no naked fire, explosion prevented. The power is adjustable from OW to 600W |
1. Initial heating: (14~17) °C/min 2. It is (5-6) °C/min after reaching the preset flash point 20 °C |
|
Igniting Device |
(1) Ignition source: coal gas(or civil gas) (2) Flame diameter is 3.2mm~4.8mm |
Electric ignition Diameter of igniter: 0.7mm~0.8mm |
|
Flash Point Determination |
|
Range: Ambient to 400°C Accuracy: 0.1 °C |
|
Power Supply |
AC220V±10%, 50Hz |
|
|
Dimension(W*D*H) |
350*290*350mm |
510*320*330mm |
|
Package Size(W*D*H) |
650*450*420mm |
6690*500*610mm |
|
Gross Weight |
20kg |
35kg |
