Features:
* Overall structure assembly, easy installation, unique technology to achieve zero pressure start.
* International famous brand, United States UOP molecular sieve, long-term stable operation. .
* Brand–type air compressor, trouble-free operation for 30000 hours.
* Professional oxygen filter, improve filtration efficiency.
* Precision gas mass flow controller, real-time measurement and control of oxygen flow.
* 10 inch color human-computer interaction interface, automatic control, easy to use.
Technical Parameter:
Model | BSZY-6 | BSZY-10 | |
Oxygen Supply Flow(m³/h) | 3.0 | 6.0 | 10.0 |
Oxygen Concentrations | ≥90% | ||
Oxygen Outlet Pressure | 0.2~0.5MPa adjustable | ||
Consumption(kW) | 9 | 13 | 25 |
Power Supply | 380V 50Hz | ||
Noise | ≤85dB(A) | ||
Using Temp. | 5~40℃ | ||
Environmental Humidity | ≤80% | ||
External Size(mm) | 1900*1350*1950 | 1900*1350*2200 | |
Package Size(mm) | 2070*1520*2100 | 2070*1520*2350 | |
Net/Gross Weight(kg) | 960/1120 | 1000/1160 | 1300/1500 |
