Features:
* Automatic paraffin melting, filtering, paraffining, gatch making, heat preservation according to the setting number of gatch disc and gatch thickness, real-time monitoring of machine working status.
* Clock function: the real-time can be set and calibrated.
* Reservation function: make an appointment in advance, shorten the waiting time for gatch making and improve efficiency.
* Constant temperature function: keep the warm of gatch, easy to use.
* Power-off memory function: in case of unexpected power failure, continue the working state before the power failure if the power supply can be restarted within 10 minutes.
* Automatic paraffin release mode and one-button paraffin release mode can be performed.
* Display function: large-screen color LCD touch screen, real-time display of running status.
* Multiple filtration function: multiple filtration system is used to ensure the purity of the paraffin liquid.
* Disc number selection function: you can choose to make 5, 10, 15 plates of gatch according to different clinical needs.
* Thickness adjustment function: gatch thickness is set as required, 10-20mm thickness is optional.
* Countdown function: The countdown status is displayed in real time during the gatch making process, which is convenient to grasp the gatch making time.
* Observation and lighting function: with a large observation window and LED lighting system, convenient to observe the gatch production at any time
* Anti-blocking function: all paraffin tubes are wrapped with carbon fiber wire for heating and insulation to prevent paraffin tube blockage.
* Air duct system: scientific air duct system to ensure uniform solidification of gatch.
* Equipment material: the appearance is made of anti-static coating, the inner room is made of 304 stainless steel, controlled by Siemens PLC, and the accessories are national certified products to ensure high quality.
* Safety performance: with overheating power protection, leakage circuit protection, to ensure safer use.
Technical Parameters:
|
Model |
BLL-15A |
|
Gatch Disc Number |
5, 10, 15 |
|
Gatch Thickness |
10-20mm adjustable |
|
Heating Temp. of Melting Paraffin Box |
60~95℃ adjustable, the adjustment interval is 1℃, temp. precision is ±5℃ |
|
Heating Temp. of Incubator |
35~62℃ adjustable, the adjustment interval is 1℃, precision is ±2℃ |
|
Ambient Temp. |
+5°C~+35°C |
|
Continuous Working Time |
>4h
|
|
Power Supply |
220V，50Hz |
|
Power |
2600VA |
|
650*750*1520mm |
|
|
Package Size(W*D*H) |
850*1000*2000mm |
|
Net Weight |
275kg |
|
Gross Weight |
310kg |
