Application:
Mainly used for concentration, crystallization, drying, separation and solvent recovery in pharmaceutical, chemical and biopharmaceutical industries.
Features:
* Double sealing rings with Teflon and Viton makes vacuum up to -0.098Mpa.
* Intelligent temperature control and digital temperature display.
* High evaporating and recovery collecting rate.
* Overloading protect function.
* Expandable module design.
* Stepless speed controller.
Model:
|
Model |
RE-2010 |
|
Rotary Bottle |
1L24# (standard size) |
|
Collecting Bottle |
1L 35# (ball mill mouth) |
|
Condenser |
Verticalφ80*370mm |
|
Charging Valve |
19# (standard size) |
|
Rotating Speed |
0~200rpm |
|
Vacuum |
-0.098Mpa |
|
Temp. Range |
RT~99°C |
|
Temp. Accuracy |
±1°C |
|
Stroke Height |
100mm+150mm(sliding + manual) |
|
Rotary Motor |
40W |
|
Heating Power |
1.3KW |
|
Water Evaporating Speed |
20ml/min |
|
Vacuum Sealing |
Double sealing rings made of Teflon+ Viton materials |
|
Shelf Material |
Aluminum alloy |
|
Chamber Material |
Aluminum alloy +Teflon φ240*140mm |
|
Power Supply |
AC220/110 V±10%,50/60 Hz |
|
External Size(W*D*H) |
570*400*630~880mm |
|
Package Size(W*D*H) |
730*550*400mm |
|
Gross Weight |
16Kg |
|
Standard Accessory |
1L Rotary Bottle*1, 1L Collecting Bottle* 1 |
|
Optional Accessory |
Vacuum pump, Recirculating chiller |
