In heavily contaminated wastewater or chemical processing applications, an inline pH probe typically wears out fast. Constantly replacing an inline pH probe can feel like a waste of time and money. We created our modular, quick disconnect S8000 sensor packages for these types of heavy duty industrial applications. The sensor can be replaced in a few seconds with no tools or re-wiring required by swapping the S8000CD Quick Change Replacement Cartridge. Reuse the cable assembly and other mounting hardware for a low cost of ownership.
Digital Communication for More Process Visibility:
- Modbus and 4-20 mA output options now available
- Configuration and calibration can be done using web based software
- Customizable, Configurable,and Versatile
- Customizable packages reduce total cost of ownership!
- Only purchase the components you need
- Adapt the solution to your application requirements
- Available in 2 standard cable lengths: 10 and 20 feet
- Reduce Maintenance and Downtime
- No tools or rewiring needed for replacing sensor cartridge
- Flat glass measurement surface reduces the threat of breakage
- Heavy duty high temperature reference gels offer protection against thermal breakdown
- PPS body allows for durability in a range of chemical environments
- ERP technology protects the reference cell and prevents contamination
pH Range 0 – 14pH (0-12.3pH with low Na+ ion error)
Temperature Range
- 0-100°C, de-rated under pressure
- 0-80°C when mounted in flow cell
- 70°C with submerged electronic module
Pressure Range: 0-100 psig (7.5 Bar), de-rated under temperature
Reference Type: Double Junction, Sensorex ERP System
| Thomas No | Mfr No | Description |
|---|---|---|
| 1141R19 | S8400 | Submersion Process pH Sensor KIT 10ft |
| 1141R20 | S8500 | Submersion Process pH Sensor KIT 20ft |
