Features:
* All-metal structure multi-layer explosion-proof design, strong and durable.
* Embedded microprocessor control, DC brushless motor drive, maintenance free, smooth operation.
* 5 inch touch LCD screen, real-time display all running parameters, the operation interface is intuitive and simple.
* Support small language customization,
* Mechanical and electrical integration door lock, easy to use, safe and reliable.
* Silicone integral sealing ring to avoid aerosol overflow.
* With self-test, block, overspeed, imbalance, over temperature detection and alarm functions, excellent shock absorption device.
* Store multiple groups of user-defined programs, boot for the last program.
Technical Parameter:
|
Model |
BKC-TL5C |
|
Max.Speed |
5000rpm |
|
Max.RCF |
3894×g |
|
Max.Capacity |
4*500ml |
|
Speed Precision |
±10rpm |
|
Time Range |
1min~99h59min |
|
Power Supply |
AC110/220V 50/60Hz |
|
Noise |
≤65dB(A) |
|
External Size(L*W*H) |
500*620*410mm |
|
Package Size(L*W*H) |
596*736*673mm |
|
Net/Gross Weight |
56/70kg |
Rotor:
|
Type |
NO. |
Capacity |
Max.Speed(rpm) |
Max.RCF(×g) |
Adapter |
|
Swing Rotor |
5M00024 |
48*3/4/5/7ml |
4000 |
2952 |
/ |
|
5M00025 |
48*3/4/5/7ml |
2952 |
/ |
||
|
5M00029 |
16*15/10ml |
2957 |
/ |
||
|
5M00030 |
24*15/10ml |
2957 |
/ |
||
|
5M00031 |
32*15/10ml |
2952 |
/ |
||
|
5M00032 |
4*50ml |
5000 |
4626 |
/ |
|
|
5M00033 |
8*50ml |
4000 |
2952 |
/ |
|
|
5M00034 |
4*100ml |
5000 |
4807 |
/ |
|
|
5M00036 |
8*100ml |
4000 |
3077 |
/ |
|
|
5M00038 |
4*250ml |
4200 |
3065 |
40*1.5(▲), 40*2ml(*), 24*10ml(▲), 24*10ml(*), 20*15ml， 4*50ml（▲）, 8*50ml, 4*100ml |
|
|
5M00039 |
4*500ml |
4000 |
3130 |
/ |
|
|
Microplate rotor |
5M00045 |
2*2*96well |
4000 |
2361 |
/ |
