Features:
* It tests clarity of injection and bottled medicine liquid
* Auto-control, auto-detection, auto-diagnosis and auto-alarm.
* Auto-temperature control and high temperature control precision.
* Auto-time control and auto-timing shutdown.
* Auto-display, auto-latching, auto-reset and auto-cyclic test.
* Automatic control of friability and high control precision for cylinder rotation speed and number of turns.
* Hardness high-precision pressure sensor, digital display of hardness value.
* Continuous measurement of tablet hardness value, manual tablet feeding, motor control and automatic compression.
* Two-path disintegration operates at the same time, automatic timing shutdown.
* Imported SUS316 stainless steel is adopted for dissolution rotation baskets and paddle rods, etc.
Technical Parameters:
|
Model |
TFUT-3 |
|
Temperature Range |
(20~40°C)±0.3°C |
|
Speed Range |
(20-200rpm)±2rpm |
|
Automatic Time Range |
(1~900min)±0.5min |
|
Stations of Dissolution |
3 |
|
Paddle Radial Run-out |
±0.5mm |
|
Basket Radial Run-out |
±1.0mm |
|
Basket Assemblies |
2 |
|
Nacelle Back and Forth Frequency |
(30~32)times/min |
|
Nacelle Back and Forth Range |
(55±2)mm |
|
Drum |
1 |
|
Drum’s Inner Size |
φ286*H39mm |
|
Tablet Fall Height |
156mm |
|
Rotating Speed |
(25±1 )times/min |
|
Rotating Count |
(100±1)turns |
|
Hardness Range |
(25~199)±1N |
|
Diameter Range |
(3~40)mm |
|
Power Supply |
AC110/220V±10%» 50/60HZ |
|
DimensionsW*D*H)mm |
520*380*470 |
|
Packing Size(W*D*H)mm |
700*440*680 |
|
Gross Weight(kg) |
45 |
