Features:
* Automation: auto-test, auto-diagnose, auto-alarm.
* Intelligently control the rotating speed of cylinder and revolutions.
* One drum runs synchronously. Auto stop at timing point, (only for TFT-4)
* Single path and double cylinder, synchronous operation and automatic stop.
* The revolution of the drum can be preset at any time, either preset or real data is displayed on the LCD.
* Microprocessor unit is used to control all operations, high accuracy is achieved in testing rotary speed and circle number.
Technical Parameters:
Model | TFT-1 | TFT-2 | TFT-3 | TFT-4 |
Cylinder Number | 2 | 1 | ||
Cylinder Radius | 286 | |||
Cylinder Depth | 39mm | |||
Tablet Fall Height | 156mm | |||
Rotating Speed | 20~100rpm | 25rpm | ||
Rotation Count | 5-900 turns | 100 turns | 5-900 turns | 10-900 turns |
Consumption | 40W | 20W | 50W | |
Power Supply | AC110/220V±10%, 50/60HZ | |||
External Size(W*D*H)mm | 370*300*340 | 300*200*340 | ||
Package Size(W*D*H)mm | 440*400*525 | 410*295*430 | ||
Gross Weight(kg) | 12 | 8 | ||
