Features:
* LCD Display. High-precision pressure sensor ensures the precision and reproducibility of test.
*Easy operation: Manual loading and manual tablet compressing for THT-1, manual single tablet and automatic continuation for THT-2/3.
*Automatic display, automatic latching, automatic reset, automatic cycle test, automatic linear error correction and automatic fault diagnosis.
* Unit conversion function, can realize the conversion before or after the tests.
* Strong data processing ability; statistics, analysis, printing and display are available for test result, (only for THT-2)
* Built-in printer, (only for THT-2)
Technical Parameters:
Model | THT-1 | THT-2 | THT-3 |
Test Range | 2~200N(0.2~20kg) | 2~200N/500N(0.2~20kg) Customize: 2~500N(0.2~50kg) | |
Resolution | 0.1N 0.01kg | ||
Accuracy | ±0.5% | ||
Probe Procession Range | 2~20mm | 2~40mm | |
Consumption | 10W | 40W | |
Power Supply | AC110/220V±10%, 50/60HZ | ||
Dimensions(W*D*H)mm | 280*180*110 | 500*400*160 | 400*240*140 |
Package Size(W*D*H)mm | 420*300*230 | 600*350*250 | 500*350*250 |
Gross Weight(kg) | 6 | 12 | 10 |
