Application places:
hospitals, scientific research institutions, maternity and child hospitals, community clinics.etc
Features
1.The test speed is fast and can be used for mass physical examination.
2.Large LCD touch screen,convenient man-machine interaction.
3.Cutting-edge computer vision technology, more accurate and reliable.
4.Traceability:The inspection results and photo can be archived, convenient for users to review.
5.Automatic induction strip, automatic unloading strip, automatic abnormal results reminder.
Technical Parameters:
Model | BH-NY01 |
Principle | Computer vision detection technology |
Throughput | 700Tests / hour |
Screen | 7-inch touch screen |
Memory | Large-capacity storage ,Support multiple detection record query modes |
Printer | Built-in thermal printer |
Working Condition | Temperature: 5-40℃ ; Humidity: <85% |
Interface | USB, support data export; Barcode scanner(optional) |
Range of Application | 11, 14 Test strip |
Items | 11 Test strip: GLU, BIL, KET, SG, PH, BLO, PRO, URO, NIT, LEU, VC; |
Power Supply | AC100-240V,50/60Hz, 40VA |
Net Weight | 4kg |
Gross Weight | 8kg |
External Size(W*D*H) | 346*320*206mm |
Package Size(W*D*H) | 425*385*305mm |
