Features:
* 3D curve shape design.
* Special gear with low noise.
Technical Parameters:
|
Model |
BKBM-V0.4 |
BKBM-V2 |
|
Capacity |
0.4L |
2L |
|
Volume of Each Capacity |
50-100ml |
50~500ml |
|
Pot Quantity |
4 pcs |
|
|
Running Time Range |
1~9999min |
|
|
Reciprocal Running Time |
1~999min |
|
|
Adjustable, Revolution |
45~435rpm |
35~335rpm |
|
SpeedRotation |
90~870rpm |
70~670rpm |
|
Noise |
58±5dB |
60±5dB |
|
Speed Control Mode |
Frequency Control |
|
|
Transmission Mode |
Gear Drive |
|
|
Working Mode |
2 or 4 pots can be used each time |
|
|
Maximum Sample Volume (material + grinding ball) |
2/3 of the volume of the ball mill tank |
|
|
Feed Size |
Soft and Crispy material<10mm, Other materials<3mm |
|
|
Out-put Granularity |
Minimum Granularity can be reached to 0.1um |
|
|
Adjusting Mode of Rotate Speed |
Frequency converter with stepless speed regulation |
|
|
Consumption |
0.25KW |
0.75KW |
|
Power Supply |
AC110/220V±10%, 50/60HZ |
|
|
External Size(W*D*H)mm |
530*300*340 |
750*470*565 |
|
Package Size(W*D*H)mm |
595*360*485 |
820*530*720 |
|
Net Weight(kg) |
29 |
80 |
|
Gross Weight(kg) |
50 |
100 |
|
Note: Both pot and ball are optional. For a ball mill with a capacity of 2L, if the matching mill pot specification is 25ml or 50ml, you need to purchase a base holder separately. |
||
