Technical Parameters:
Model | BKBM-V2S | |
Capacity | 2L | |
Volume of Each Capacity | 50~500ml | |
Pot Quantity | 4pcs | |
Running Time Range | 1~9999min | |
Reciprocal Running Time | 1~999min | |
Adjustable Speed | Revolution | 35~335rpm |
Rotation | 70~670rpm | |
Noise | 60±5dB | |
Speed Control Mode | Frequency Control | |
Transmission Mode | Gear Drive | |
Working Mode | 2 or 4 pots can be used each time | |
Maximum Sample Volume (material + grinding ball) | 2/3 of the volume of the ball mill tank | |
Feed Size | Soft and Crispy material<10mm, Other materials<3mm | |
Out-put Granularity | Minimum Granularity can be reached to 0.1um | |
Adjusting Mode of Rotate Speed | Frequency converter with stepless speed regulation | |
Consumption | 0.75KW | |
Power Supply | AC110/220V±10%, 50/60HZ | |
External Size(W*D*H)mm | 770*470*570 | |
Package Size(W*D*H)mm | 820*540*680 | |
Net Weight(kg) | 93 | |
Gross Weight(kg) | 113 | |
Note: Both pot and ball are optional. Fora ball mill with a capacity of 2L, if the matching mill pot specification is 25ml or 50ml, you need to purchase a base holder separately. | ||
