Water-Jacketed CO2 Incubator with TC Sensor 115V

Choice of T/C or IR Sensor
Select a T/C sensor when chamber temp and RH are relatively constant.
Typically, a T/C sensor has a longer life than an IR sensor.
Select an IR sensor when temp and RH levels are changed frequently. With either sensor, elevated RH is critical to prevent desiccation

Description

Water Jacketed Chamber

• The 184L (6.5 cu. ft.) high capacity chamber provides outstanding culturing space
• Standard right hand door swing, field reversible
• Polished stainless steel interior with coved corners is easy-to-clean with removable humidity pan
• Unique triple wall construction provides outstanding temperature uniformity and stability
• Exclusive, heated dual pane inner glass door is designed to minimize condensation
• In-chamber fan gently distributes air throughout the chamber which is designed ensure homogeneous conditions
• Sturdy stainless steel shelves and supports can be removed without tools for easy cleaning or adjustment

ISO Class 5 HEPA Filtration Airflow System

• In-chamber HEPA air filtration continuously filters entire chamber volume every 60 seconds
• Reaches ISO Class 5 (Class 100) cleanroom air quality in only 5 minutes after door opening
• Continuous protection by minimizing ability for contaminants to settle on interior surfaces

In situ Sensors and Probes Designed for Precise Monitoring

• Choice of TC (thermal conductivity) CO2 sensor for long, reliable operation or IR (infrared) CO2 sensor for monitoring when humidity and temperature are less predictable
• Dual temperature probes with over temperature protection
• Optional rH display for monitoring humidity levels to prevent “dry-outs”

Enviro-Scan Microprocessor Control

• Easy- to-use, alphanumeric LED display
• Flexible, intuitive controls with message center including process and alarm status messages
• Configurable audible on/off, access code, tracking low and high alarms
