Control Modes
Set points for control operations can be configured to be on/off, proportional, or PID types of control. The flexibility in programming allows for fine-tuning of a set point to be maintained with tight control preventing any overshoot and waste of chemicals.
Hold Function
Hold can also be triggered manually and by using and external digital input for disabling control mode when performing maintenance.
Configurable Alarm System
Configurable for set points and temperature or activated by abnormal operation, a red Alarm LED will blink and can easily be seen from a distance. All relays configured for control are inactivated until the alarm state is resolved.
Auto-cleaning cycle
The cleaning function allows the ability to program one or more wash cycles and use the relays to activate valves, pumps or compressed air based on the type of washing that is required to maintain probes for reliable results.
Relays
Available with up to five electromechanical control relays and one alarm relay.
Analog Outputs
Up to four galvanically isolated analog outputs for control of pumps and valves.
Digital RS485 Output
Can daisy-chain up to 32 devices to a remote monitoring system.
Digital Inputs
Two digital inputs available for modes including disabling, cleaning and placing the controller into hold status?.
