Features:
* Cooling system adopt TECUMSEH compressor in order to ensure cooling efficiency, and reduce noise.
* PID temperature controlling technology is adopted. Cooling method
is not the traditional start-stop type, EEV technology improve the stability.
* Over-temperature protection and auto-alarm function is used in refrigeration control system to avoid damage temperature medium caused by abnormal liquid temperature value.
* Water level observation window and automatic water level detection device, automatic alarm when low liquid level.
* Water current detection device is adopted. When external cycle closed or blocked, internal cycle will be switched automatically.
* High performance circulating water pump guarantee the long time continuous running, and good sealing avoid leakage. The pressure of pump is 0~1.5 bar, adjustment is available by rotary knob. Pressure value is displayed.
* Color LCD screen display more running data and dynamic identifier. Easy to monitor.
Technical Parameters:
|
Model |
BK-RC1200 |
|
|
Temp. Control Range |
5°C ~ 40°C |
|
|
Temp. Control |
PID |
|
|
Temp. Stability |
±0.3°C |
|
|
Temp. Sensor |
PT100 |
|
|
Display Resolution |
0.1°C |
|
|
Pump Flow Rate |
20L/min |
|
|
Cooling Consumption |
1.2KW |
|
|
Refrigerant |
R134a |
|
|
Pump Capacity Pressure |
0-1.5 bar |
|
|
Filling Volume |
8L |
|
|
Power Supply |
AC220V±10%, 50Hz |
|
|
External Size(W*D*H) |
550*400*650mm |
|
|
Package Size(W*D*H) |
810*640*980mm |
|
|
Gross Weight |
87kg |
|
