Technical Parameters:
|
Model |
CCA-420 |
DLSB-5/20 |
DLSB-20/40 |
|
Temp. Display |
LED display |
||
|
Tank Volume |
4L |
6.8L |
20L |
|
Matching Reaction Kettle(Steam) |
1~2L |
1~5L |
20L |
|
Tank Material |
304 Stainless Steel |
201 Stainless Steel |
|
|
Tank Size |
250*130*130mm |
φ220*180mm |
φ300*300mm |
|
Temp. Control Accuracy |
±0.1 °C |
||
|
Display Temp. Resolution |
0.1°C |
||
|
Pump Lift |
1.5~2.7m |
4~6m |
|
|
Circulating Pump Flow |
8~16L/min |
20~40L/min |
|
|
Refrigerant |
R134A |
R22 |
|
|
Refrigerating Capacity |
1550-500W |
2324-735W |
6972-2205W |
|
Pressure |
≤0.4Mpa |
||
|
Ambient Relative Humidity |
(60~80%)Ventilation |
||
|
Instrument Temp. Control Range |
-20°C~RT |
-40°C~RT |
|
|
Optimum Ambient Temp. |
5~35°C |
||
|
Unload Min Temp. |
–20°C |
-20°C |
-42°C |
|
Circulation Pump Power |
100W |
||
|
Circulating Pump |
Magnetic pump |
Fully-closed &No-leaked special pump |
|
|
Circulating Water Mouth Interface |
Outer diameterl 1 mm/ Inner diameter7mm |
|
|
|
Sensor |
PT100 |
||
|
Coil Diameter |
|
φ185mm |
φ255mm |
|
Opening Size |
|
φ200mm |
φ250mm |
|
Power Supply |
AC220V±10%, 50/60HZ |
AC220±10%,50y60Hz； AC110±10%, 60Hz |
AC220V±10%, 50/60HZ |
| Model | CCA-420 | DLSB-5/20 DLSB20/40 | |||||
| Secure Protection | Overload protection, Overheating protection, Refrigerator delay protector |
Leakage,overload circuit breaker,Overload relay circuit,Refrigerator protection timer,Circulating pump thermal protector,Refrigerator high-pressure pressure switch,Temperature control self-diagnosis function |
|||||
| External Size(W*D*H)mm | 520*250*560 | 485*423*(760+400) | 590*670*(975+500) | ||||
| Package Size(W*D*H)mm | 580*310*560 | 595*435*880 | 725*595*1130 | ||||
| Gross Weight(kg | 30 | 65 | 122.5 | ||||
| Accessories | In and out joint *1 silicone pipe insulation*2 |
In and out joint *1,Vertical rod*1, Thermal insulation pipe*2 |
|||||
| Applicable Rotary Evaporator Model |
RE-2010,RE-2000A,RE-2000B, RE-2000E,RE-52A,RE-52C RE-5299,RE-201D,RE 100-Pro |
RE-301,RE-501 | RE-1002,ExRE-1002, RE-2002 |
||||
