Features:
Model | BK-P685 | BK-P682 |
Measurement Range | R.T.~400℃ | R.T.~360℃ |
Measurement Mode | Automatic/visual (high-definition carnera, video caplure, playback monitoring) | |
Measurement Methods | 200 | 150 |
User name/password hierarchical management | 200 | 150 |
Audit Trail | Optional (FDA) | |
Electronic Signature | YES | |
Minimum Digital Display | 0.1℃
| |
Linear Heating-up Rate | 0.1℃/min~20℃/min | |
Accuracy | ≤200℃±0.3℃; >200℃±0.5℃ | |
Repeatability | 0.3℃ (heating rate: 1.0℃/min) | |
Linear Heating Rate Error | ±10%
| |
Number of Capillary | 4 | |
Capillary Dimensions | Outer diameter: Φ1.4mm, Inner diameter:Φ1.0mm, Height:90mm | |
Height of Sample | 3mm | |
Operation System | Android | |
Date Storage | 128G | 64G |
Display | 10.1 inches capacitive touch screen | |
Graph Storage | 40000 | 20000 |
Interface | 1*RS232, 3*USB, 1*RJ-45, WIFI | |
Power Supply | 100~240V, 50/60Hz, 150w | |
Package Size | 495*493*350mm | |
Gross Weight | 5kg | |
